Methodological aspects of strength testing of building products based on thermoplastic waste

Cover Page

Cite item

Full Text

Open Access Open Access
Restricted Access Access granted
Restricted Access Subscription or Fee Access

Abstract

The urgency of the problem of recycling polymer waste is increasing every year. It is promising to use thermoplastic waste as binders in polymer-mineral compositions for the production of small-piece construction products such as paving slabs, curbs, parking limiters, elements of landscape design, etc. Technical requirements for the compositions of polymer-mineral compositions, the properties of their products, test methods are not regulated. One of the most informative characteristics is static uniaxial compression tests. It is necessary to accumulate statistics on strength tests of composites based on secondary thermoplastics and develop mathematical patterns of the influence of sample size, primarily their thickness, on strength properties. Therefore, the work is aimed at improving the methodological aspects of assessing the compressive strength of polymer-mineral samples based on thermoplastic matrices. Crushed polymer waste of polyethylene terephthalate and polypropylene, a combination additive ethylene vinyl acetate, and limestone flour were used to make the samples. Samples of various thicknesses were made by pressing from hot mixtures, then their compressive strength was determined. As a result, a differentiated approach to the geometry of the samples is proposed, taking into account the peculiarities of their manufacture and the complexity of obtaining samples of exactly the same thickness. A linear basic dependence of strength on the thickness of the sample is obtained, and a method for calculating compressive strength from the experimental thickness of the sample to the control one is proposed. It is proposed to take the sample thickness of 4 cm as a control, by analogy with the current standards for cement composites. Using the basic dependence and the proposed conversion method, it is possible to design formulations of compositions using various powdered mineral fillers (filling degree of more than 50% by weight) and various thermoplastic wastes, combining rigid thermoplastic polyethylene terephthalate and polyolefins in compositions.

Full Text

Restricted Access

About the authors

N. N. Fomina

Yuri Gagarin State Technical University of Saratov

Author for correspondence.
Email: fominanani@yandex.ru

Candidate of Sciences (Engineering)

Russian Federation, 77, Polirechnicheskaya Street, Saratov, 410054

D. K. Timokhin

Yuri Gagarin State Technical University of Saratov

Email: voiced@list.ru

Candidate of Sciences (Engineering)

Russian Federation, 77, Polirechnicheskaya Street, Saratov, 410054

A. V. Strachov

Yuri Gagarin State Technical University of Saratov

Email: strachov83@mail.ru

Candidate of Sciences (Engineering)

Russian Federation, 77, Polirechnicheskaya Street, Saratov, 410054

V. G. Fomin

Yuri Gagarin State Technical University of Saratov

Email: foma777@rambler.ru

Candidate of Sciences (Physics and Mathematics)

Russian Federation, 77, Polirechnicheskaya Street, Saratov, 410054

References

  1. Chidepatil A., Cardenas J.F.M., Sankaran K. Circular economy of plastics: wishful thinking or a way forward? Journal Of The Institution Of Engineers (India): Series C. 2022. Vol. 103, pp. 647–653. EDN: QVJQIS. https://doi.org/10.1007/s40032-021-00767-8
  2. Muzalev S.V., Nikiforova E.V., Petrova O.A., Antonova O.V., Mel’nikova L.A. Recycling of solid municipal waste in construction. Stroitel’nye Materialy i Izdeliya. 2023. Vol. 6 (5), pp. 5–7. (In Russian). EDN: IQJNPZ. https://doi.org/10.58224/2618-7183-2023-6-5-7
  3. Vorona-Slivinskaya L.G. Regional solid waste management plans: distinctive features of practice In Russia and EU countries. Stroitel’nye Materialy i Izdeliya. 2023. Vol. 6. (3), pp. 98–118. (In Russian). EDN: HVAKPD. https://doi.org/10.58224/2618-7183-2023-6-3-98-118
  4. Baruzdin A.A., Zakrevskaya L.V. Composite materials based on construction and polymer waste. Vestnik MGSU. 2024. Vol. 19. No. 2, pp. 246–257. (In Russian). EDN: QXPYOO. https://doi.org/10.22227/1997-0935.2024.2.246-257
  5. Al-Mansour A., Chen Sh., Xu Ch., Peng Y., Wang J., Ruan Sh., Zeng Q. Sustainable cement mortar with recycled plastics enabled by the matrix-aggregate compatibility improvement. Construction and Building Materials. 2022. Vol. 318. 125994. EDN: PWJMZU. https://doi.org/10.1016/j.conbuildmat.2021.125994
  6. Al-Mansour А., Xu Ch., Yang R., Dai Y., Dang N., Lan Y., Zhang M., Fu Ch., Gong F., Zeng Q. Unleashing high-volume waste plastic recycling in sustainable cement mortar with synergistic matrix enabled by in-situ polymerization. Construction and Building Materials. 2024. Vol. 447. 138031. EDN: MIZZSO. https://doi.org/10.1016/j.conbuildmat.2024.138031
  7. Chen Sh., Liu R.-А., Huang X.-Y., Yang Z.-M., Lin J.-X. PET particles modify strain hardening cementitious composites: An approach to introduce defects to enhance deformation capacity. Construction and Building Materials. 2024. Vol. 447. 138064. EDN: WZLWQL. https://doi.org/10.1016/j.conbuildmat.2024.138064
  8. Kumi-Larbi Jnr Al., Yunana D., Kamsouloum P., Webster M., Wilson D.C., Cheeseman Ch. Recycling waste plastics in developing countries: Use of low-density polyethylene water sachets to form plastic bonded sand blocks. Waste Management. 2018. Vol. 80, pp. 112–118. https://doi.org/10.1016/j.wasman.2018.09.003
  9. Dalhat M.A., Al-Abdul Wahhab H.I. Cement-less and asphalt-less concrete bounded by recycled plastic. Construction and Building Materials. 2016. Vol. 119, pp. 206–214. https://doi.org/10.1016/j.conbuildmat.2016.05.010
  10. Zaichenko N., Nefedov V. Composite material based on the polyethylene terephthalate polymer and modified fly ash filler. MATEC Web of Conferences. 2018. Vol. 245. 03007. EDN: BOWRSL. https://doi.org/10.1051/matecconf/201824503007
  11. Thiam M., Fall M. Engineering properties of a building material with melted plastic waste as the only binder. Journal of Building Engineering. 2021. Vol. 44. 102684. EDN: ALWGLB. https://doi.org/10.1016/j.jobe.2021.102684
  12. Thiam M., Fall M., Diarra M.S. Mechanical properties of a mortar with melted plastic waste as the only binder: Influence of material composition and curing regime, and application in Bamako. Case Studies in Construction Materials. 2021. Vol. 15. e00634. EDN: LVSJMZ. https://doi.org/10.1016/j.cscm.2021.e00634
  13. Thiam M., Fall M. Mechanical, physical and microstructural properties of a mortar with melted plastic waste binder. Construction and Building Materials. 2021. Vol. 302. 124190. EDN: GVCFMK. https://doi.org/10.1016/j.conbuildmat.2021.124190
  14. Slieptsova I., Savchenko B., Sova N., Slieptsov A. Polymer sand composites based on the mixed and heavily contaminated thermoplastic waste. IOP Conference Series: Materials Science and Engineering. 2016. Vol. 111. 012027. EDN: XMMNTP. https://doi.org/10.1088/1757-899X/111/1/012027
  15. Dhawan R., Bisht B. M. S., Kumar R., Kumari S., Dhawan S.K. Recycling of plastic waste into tiles with reduced flammability and improved tensile strength. Process Safety and Environmental Protection. 2019. Vol. 124, pp. 299-307. https://doi.org/10.1016/j.psep.2019.02.018
  16. Mahdi F., Abbas H., Khan A. Flexural, shear and bond strength of polymer concrete utilizing recycled resin obtained from post consumer PET bottles. Construction and Building Materials. 2013. Vol. 44, pp. 798–811. https://doi.org/10.1016/j.conbuildmat.2013.03.081
  17. Lee T.S., Lee J., Ann K.Y. Manufacture of polymeric concrete on the Moon. Acta Astronautica. 2015. Vol. 114, pp. 60–64. https://doi.org/10.1016/j.actaastro.2015.04.004
  18. Fomina N.N., Khozin V.G. Compatibilization of polymer mixtures during processing of waste products from thermoplastics. Nanotechnologies in Construction. 2021. Vol. 13 (4), pp. 229–236. EDN: GVRGKU. https://doi.org/10.15828/2075-8545-2021-13-4-229-236
  19. Patent RF 2623754. Smes’ dlya polucheniya kompozitsionnykh stroitel’nykh materialov [Mix for the composite building materials production]. Ivashchenko Yu.G., Fomina N.N., Polyansky M.M. Declared 29.03.2016. Published 29.06.2017. Bull. No. 19. (In Russian).
  20. Fomina N.N., Khozin V.G. Thermoplastic binder from polymer waste. Stroitel’nye Materialy [Construction Materials]. 2021. No. 1–2, pp. 105–114. EDN: VADDQP. https://doi.org/10.31659/0585-430X-2021-788-1-2-105-114
  21. Vincent G.A., Bruijn Th.A., Wijskamp S., Rasheed M.I. A., Drongelen M., Akkerman R. Characterisation and improvement of the quality of mixing of recycled thermoplastic composites. Composites Part C: Open Access. 2021. Vol. 4. 100108. EDN: XXQJBM. https://doi.org/10.1016/j.jcomc.2021.100108
  22. Mel’nikov D.A., Il’ichev A.V. Vavilova M.I. Comparison of standards for mechanical testing of fiberglass composites under compression. Trudy VIAM. 2017. No. 3 (51), pp. 55–64. (In Russian). EDN: YGASIX. https://doi.org/10.18577/2307-6046-2017-0-3-6-6
  23. Siva Naga Sai Goli V., Mohammad A., Narain Singh D. Application of municipal plastic waste as a manmade neo-construction material: issues & wayforward. Resources, Conservation and Recycling. 2020. Vol. 161. 105008. EDN: IZDETM. https://doi.org/10.1016/j.resconrec.2020.105008

Supplementary files

Supplementary Files
Action
1. JATS XML
Download
2. Fig. 1. Linear dependences of Rсж on the sample thickness, in three thickness ranges: up to 2 cm (a); from 2 to 3 cm (b); from 3 cm (c)

Download (156KB)
Indexing metadata
3. Fig. 2. Basic dependence of Rсж on thickness for samples made from compositions of this type

Download (98KB)
Indexing metadata
