Emission of Shock-Heated Air in the Vacuum Ultraviolet Spectral Region

N. G. Bykova; Быкова Н. Г.; I. E. Zabelinskii; Забелинский И. Е.; P. V. Kozlov; Козлов П. В.; G. Ya. Gerasimov; Герасимов Г. Я.; V. Yu. Levashov; Левашов В. Ю.

doi:10.31857/S0207401X23100047

Emission of Shock-Heated Air in the Vacuum Ultraviolet Spectral Region

Authors: Bykova N.G.¹, Zabelinskii I.E.¹, Kozlov P.V.¹, Gerasimov G.Y.¹, Levashov V.Y.¹
Affiliations:
1. Institute of Mechanics, Moscow State University, Moscow, Russia
Issue: Vol 42, No 10 (2023)
Pages: 34-41
Section: Combustion, explosion and shock waves
URL: https://vestnikugrasu.org/0207-401X/article/view/674817
DOI: https://doi.org/10.31857/S0207401X23100047
EDN: https://elibrary.ru/ROLBUM
ID: 674817

Cite item

Full Text

Open Access
Restricted Access

Access granted
Restricted Access

Subscription Access

Abstract
About the authors
References
Supplementary files
Statistics

Abstract

The results of measuring the integral and temporal spectral characteristics of shock-heated air are presented. The experiments are carried out on a modified two-sections SST-M shock tube of the Institute of Mechanics, Moscow State University in shock wave velocities ranging from 7.8 to 10.7 km/s and initial pressures in the low-pressure chamber of 0.125 and 0.25 Torr. The radiation wavelength range 115–195 nm, corresponding to the vacuum ultraviolet (VUV) spectral region, in which the main contribution to the radiation is made by the atomic lines of nitrogen and oxygen, is studied. The obtained radiation spectrograms are analyzed. The measurement data are compared with the available experimental data of other authors.

Keywords

shock waves, radiation, air, shock tube, vacuum ultraviolet, atomic emission lines

References

Shang J.S., Surzhikov S.T. // Prog. Aerospace Sci. 2012. V. 53. P. 46.
Суржиков С.Т. // Хим. физика. 2008. Т. 27. № 10. С. 63.
Brandis A.M., Johnston C.O., Cruden B.A., Prabhu D., Bose D. // J. Thermophys. Heat Trans. 2015. V. 29. P. 209.
Kleb B., Johnston C. // AIAA Paper. № 2008-3688.
Palumbo G., Craig R.A., Whiting E.W., Park C. // J. Quant. Spectrosc. Radiat. Transfer. 1997. V. 51. P. 207.
Герасимов Г.Я., Козлов П.В., Забелинский И.Е., Быкова Н.Г., Левашов В.Ю. // Хим. физика. 2022. Т. 41. № 8. С. 17.
Cruden B.A., Martinez R., Grinstead J.H., Olejniczak J. // AIAA Paper. № 2009-4240.
Brandis A.M., Cruden B.A. // AIAA Paper. № 2017-1145.
Sheikh U.A., Morgan R.G., McIntyre T.J. // AIAA J. 2015. V. 53. P. 3589.
Быкова Н.Г., Забелинский И.Е., Ибрагимова Л.Б., Козлов П.В., Стовбун С.В., Тереза А.М., Шаталов О.П. // Хим. физика. 2018. Т. 37. № 2. С. 35.
Забелинский И.Е., Козлов П.В., Акимов Ю.В., Быкова Н.Г., Герасимов Г.Я., Туник Ю.В., Левашов В.Ю. // Хим. физика. 2021. Т. 40. № 11. С. 22.
Kozlov P.V., Zabelinsky I.E., Bykova N.G., Gerasimov G.Ya., Levashov V.Yu., Tunik Yu.V. // Acta Astronaut. 2022. V. 194. P. 461.
Козлов П.В., Забелинский И.Е., Быкова Н.Г., Акимов Ю.В., Левашов В.Ю., Герасимов Г.Я., Тереза А.М. // Хим. физика. 2022. Т. 41. № 9. С. 26.
NIST Atomic Spectra Database, Ver. 5.10. Gaithersburg: NIST, 2022; https://doi.org/10.18434/T4W30F
Kazakov V.V., Kazakov V.G., Kovalev V.S., Meshkov O.I., Yatsenko A.S. // Phys. Scr. 2017. V. 92. № 105002.
Jung Y.-D., Kim C.-G. // J. Plasma Phys. 2002. V. 67. P. 191.
Tibère-Inglesse A, Cruden B.A. // J. Quant. Spectrosc. Radiat. Transfer. 2022. V. 290. № 108302.
Johnston C.O., Kleb B. // J. Spacecraft Rockets. 2012. V. 49. P. 425.
Han J., Park W., Kim J. et al. // Current Appl. Phys. 2021. V. 31. P. 208.
Han D., Park J., Kim Y., Kwon D., Park S. // Ibid. P. 239.
Суржиков С.Т. // Теплофизика высоких температур. 2016. Т. 54. № 2. С. 249.
Козлов П.В., Забелинский И.Е., Быкова Н.Г., Герасимов Г.Я., Левашов В.Ю. // Изв. РАН. МЖГ. 2022. № 6. С. 85.
